org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper クラス

org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper の継承関係図

org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper 連携図

クラス
class	MSADUserModelDelegate

公開メンバ関数
	MSADLDSUserAccountControlStorageMapper (ComponentModel mapperModel, LDAPStorageProvider ldapProvider)
void	beforeLDAPQuery (LDAPQuery query)
LDAPOperationDecorator	beforePasswordUpdate (UserModel user, LDAPObject ldapUser, PasswordUserCredentialModel password)
void	passwordUpdated (UserModel user, LDAPObject ldapUser, PasswordUserCredentialModel password)
void	passwordUpdateFailed (UserModel user, LDAPObject ldapUser, PasswordUserCredentialModel password, ModelException exception)
UserModel	proxy (LDAPObject ldapUser, UserModel delegate, RealmModel realm)
void	onRegisterUserToLDAP (LDAPObject ldapUser, UserModel localUser, RealmModel realm)
void	onImportUserFromLDAP (LDAPObject ldapUser, UserModel user, RealmModel realm, boolean isCreate)
boolean	onAuthenticationFailure (LDAPObject ldapUser, UserModel user, AuthenticationException ldapException, RealmModel realm)
SynchronizationResult	syncDataFromFederationProviderToKeycloak (RealmModel realm)
SynchronizationResult	syncDataFromKeycloakToFederationProvider (RealmModel realm)
List< UserModel >	getGroupMembers (RealmModel realm, GroupModel group, int firstResult, int maxResults)
LDAPStorageProvider	getLdapProvider ()
void	close ()

静的公開メンバ関数
static boolean	parseBooleanParameter (ComponentModel mapperModel, String paramName)

限定公開メンバ関数
boolean	processAuthErrorCode (String errorCode, UserModel user)
ModelException	processFailedPasswordUpdateException (ModelException e)

限定公開変数類
final KeycloakSession	session
final ComponentModel	mapperModel
final LDAPStorageProvider	ldapProvider

静的非公開変数類
static final Logger	logger = Logger.getLogger(MSADLDSUserAccountControlStorageMapper.class)
static final Pattern	AUTH_EXCEPTION_REGEX = Pattern.compile(".*AcceptSecurityContext error, data ([0-9a-f]*), v.*")
static final Pattern	AUTH_INVALID_NEW_PASSWORD = Pattern.compile("(?s).*problem 1005 \\(CONSTRAINT_ATT_TYPE\\), data [0-9a-f]*, Att 23 \\(userPassword\\).*")

詳解

Mapper specific to MSAD LDS. It's able to read the msDS-UserAccountDisabled, msDS-UserPasswordExpired and pwdLastSet attributes and set actions in Keycloak based on that. It's also able to handle exception code from LDAP user authentication (See http://www-01.ibm.com/support/docview.wss?uid=swg21290631 )

著者

Marek Posolda

Slawomir Dabek

構築子と解体子

MSADLDSUserAccountControlStorageMapper()

org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.MSADLDSUserAccountControlStorageMapper ( ComponentModel  mapperModel, LDAPStorageProvider  ldapProvider  )

inline

                                                                                                                {
        super(mapperModel, ldapProvider);
        ldapProvider.setUpdater(this);
    }

関数詳解

beforeLDAPQuery()

void org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.beforeLDAPQuery ( LDAPQuery  query )

inline

org.keycloak.storage.ldap.mappers.LDAPStorageMapperを実装しています。

                                                 {
        query.addReturningLdapAttribute(LDAPConstants.PWD_LAST_SET);
        query.addReturningLdapAttribute(LDAPConstants.MSDS_USER_ACCOUNT_DISABLED);

        // This needs to be read-only and can be set to writable just on demand
        query.addReturningReadOnlyLdapAttribute(LDAPConstants.PWD_LAST_SET);

        if (ldapProvider.getEditMode() != UserStorageProvider.EditMode.WRITABLE) {
            query.addReturningReadOnlyLdapAttribute(LDAPConstants.MSDS_USER_ACCOUNT_DISABLED);
        }
    }

beforePasswordUpdate()

LDAPOperationDecorator org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.beforePasswordUpdate ( UserModel  user, LDAPObject  ldapUser, PasswordUserCredentialModel  password  )

inline

org.keycloak.storage.ldap.mappers.PasswordUpdateCallbackを実装しています。

                                                                                                                                  {
        return null; // Not supported for now. Not sure if LDAP_SERVER_POLICY_HINTS_OID works in MSAD LDS
    }

close()

void org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.close ( )

inlineinherited

                        {

    }

getGroupMembers()

List<UserModel> org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.getGroupMembers ( RealmModel  realm, GroupModel  group, int  firstResult, int  maxResults  )

inlineinherited

org.keycloak.storage.ldap.mappers.LDAPStorageMapperを実装しています。

                                                                                                                {
        return Collections.emptyList();
    }

getLdapProvider()

LDAPStorageProvider org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.getLdapProvider ( )

inlineinherited

                                                 {
        return ldapProvider;
    }

onAuthenticationFailure()

boolean org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.onAuthenticationFailure ( LDAPObject  ldapUser, UserModel  user, AuthenticationException  ldapException, RealmModel  realm  )

inline

org.keycloak.storage.ldap.mappers.LDAPStorageMapperを実装しています。

                                                                                                                                         {
        String exceptionMessage = ldapException.getMessage();
        Matcher m = AUTH_EXCEPTION_REGEX.matcher(exceptionMessage);
        if (m.matches()) {
            String errorCode = m.group(1);
            return processAuthErrorCode(errorCode, user);
        } else {
            return false;
        }
    }

onImportUserFromLDAP()

void org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.onImportUserFromLDAP ( LDAPObject  ldapUser, UserModel  user, RealmModel  realm, boolean  isCreate  )

inline

org.keycloak.storage.ldap.mappers.LDAPStorageMapperを実装しています。

                                                                                                              {

    }

onRegisterUserToLDAP()

void org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.onRegisterUserToLDAP ( LDAPObject  ldapUser, UserModel  localUser, RealmModel  realm  )

inline

org.keycloak.storage.ldap.mappers.LDAPStorageMapperを実装しています。

                                                                                                 {

    }

parseBooleanParameter()

static boolean org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.parseBooleanParameter ( ComponentModel  mapperModel, String  paramName  )

inlinestaticinherited

                                                                                              {
        String paramm = mapperModel.getConfig().getFirst(paramName);
        return Boolean.parseBoolean(paramm);
    }

passwordUpdated()

void org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.passwordUpdated ( UserModel  user, LDAPObject  ldapUser, PasswordUserCredentialModel  password  )

inline

org.keycloak.storage.ldap.mappers.PasswordUpdateCallbackを実装しています。

                                                                                                           {
        logger.debugf("Going to update pwdLastSet for ldap user '%s' after successful password update", ldapUser.getDn().toString());

        // Normally it's read-only
        ldapUser.removeReadOnlyAttributeName(LDAPConstants.PWD_LAST_SET);

        ldapUser.setSingleAttribute(LDAPConstants.PWD_LAST_SET, "-1");

        if (user.isEnabled()) {
            // TODO: Use removeAttribute once available
            ldapUser.setSingleAttribute(LDAPConstants.MSDS_USER_ACCOUNT_DISABLED, "FALSE");
            logger.debugf("Removing msDS-UserPasswordExpired of user '%s'", ldapUser.getDn().toString());
        }

        ldapProvider.getLdapIdentityStore().update(ldapUser);
    }

passwordUpdateFailed()

void org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.passwordUpdateFailed ( UserModel  user, LDAPObject  ldapUser, PasswordUserCredentialModel  password, ModelException  exception  )

inline

org.keycloak.storage.ldap.mappers.PasswordUpdateCallbackを実装しています。

                                                                                                                                          {
        throw processFailedPasswordUpdateException(exception);
    }

processAuthErrorCode()

boolean org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.processAuthErrorCode ( String  errorCode, UserModel  user  )

inlineprotected

                                                                             {
        logger.debugf("MSAD LDS Error code is '%s' after failed LDAP login of user '%s'", errorCode, user.getUsername());

        if (ldapProvider.getEditMode() == UserStorageProvider.EditMode.WRITABLE) {
            if (errorCode.equals("532") || errorCode.equals("773")) {
                // User needs to change his MSAD password. Allow him to login, but add UPDATE_PASSWORD required action
                if (!user.getRequiredActions().contains(UserModel.RequiredAction.UPDATE_PASSWORD.name())) {
                    user.addRequiredAction(UserModel.RequiredAction.UPDATE_PASSWORD);
                }
                return true;
            } else if (errorCode.equals("533")) {
                // User is disabled in MSAD LDS. Set him to disabled in KC as well
                if (user.isEnabled()) {
                    user.setEnabled(false);
                }
                return true;
            } else if (errorCode.equals("775")) {
                logger.warnf("Locked user '%s' attempt to login", user.getUsername());
            }
        }

        return false;
    }

processFailedPasswordUpdateException()

ModelException org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.processFailedPasswordUpdateException ( ModelException  e )

inlineprotected

                                                                                    {
        if (e.getCause() == null || e.getCause().getMessage() == null) {
            return e;
        }

        String exceptionMessage = e.getCause().getMessage();
        Matcher m = AUTH_INVALID_NEW_PASSWORD.matcher(exceptionMessage);
        if (m.matches()) {
            ModelException me = new ModelException("invalidPasswordRegexPatternMessage", e);
            me.setParameters(new Object[]{"passwordConstraintViolation"});
            return me;
        }

        return e;
    }

proxy()

UserModel org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.proxy ( LDAPObject  ldapUser, UserModel  delegate, RealmModel  realm  )

inline

org.keycloak.storage.ldap.mappers.LDAPStorageMapperを実装しています。

                                                                                      {
        return new MSADUserModelDelegate(delegate, ldapUser);
    }

syncDataFromFederationProviderToKeycloak()

SynchronizationResult org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.syncDataFromFederationProviderToKeycloak ( RealmModel  realm )

inlineinherited

org.keycloak.storage.ldap.mappers.LDAPStorageMapperを実装しています。

                                                                                            {
        return new SynchronizationResult();
    }

syncDataFromKeycloakToFederationProvider()

SynchronizationResult org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.syncDataFromKeycloakToFederationProvider ( RealmModel  realm )

inlineinherited

org.keycloak.storage.ldap.mappers.LDAPStorageMapperを実装しています。

                                                                                            {
        return new SynchronizationResult();
    }

メンバ詳解

AUTH_EXCEPTION_REGEX

final Pattern org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.AUTH_EXCEPTION_REGEX = Pattern.compile(".*AcceptSecurityContext error, data ([0-9a-f]*), v.*")

staticprivate

AUTH_INVALID_NEW_PASSWORD

final Pattern org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.AUTH_INVALID_NEW_PASSWORD = Pattern.compile("(?s).*problem 1005 \\(CONSTRAINT_ATT_TYPE\\), data [0-9a-f]*, Att 23 \\(userPassword\\).*")

staticprivate

ldapProvider

final LDAPStorageProvider org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.ldapProvider

protectedinherited

logger

final Logger org.keycloak.storage.ldap.mappers.msadlds.MSADLDSUserAccountControlStorageMapper.logger = Logger.getLogger(MSADLDSUserAccountControlStorageMapper.class)

staticprivate

mapperModel

final ComponentModel org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.mapperModel

protectedinherited

session

final KeycloakSession org.keycloak.storage.ldap.mappers.AbstractLDAPStorageMapper.session

protectedinherited

---

このクラス詳解は次のファイルから抽出されました:

• D:/AppData/doxygen/keycloak/federation/src/federation/ldap/src/main/java/org/keycloak/storage/ldap/mappers/msadlds/MSADLDSUserAccountControlStorageMapper.java
