org.keycloak.protocol.oidc.OIDCWellKnownProvider クラス

org.keycloak.protocol.oidc.OIDCWellKnownProvider の継承関係図

org.keycloak.protocol.oidc.OIDCWellKnownProvider 連携図

公開メンバ関数
	OIDCWellKnownProvider (KeycloakSession session)
Object	getConfig ()
void	close ()

静的公開変数類
static final List< String >	DEFAULT_REQUEST_OBJECT_SIGNING_ALG_VALUES_SUPPORTED = list(Algorithm.none.toString(), Algorithm.RS256.toString())
static final List< String >	DEFAULT_GRANT_TYPES_SUPPORTED = list(OAuth2Constants.AUTHORIZATION_CODE, OAuth2Constants.IMPLICIT, OAuth2Constants.REFRESH_TOKEN, OAuth2Constants.PASSWORD, OAuth2Constants.CLIENT_CREDENTIALS)
static final List< String >	DEFAULT_RESPONSE_TYPES_SUPPORTED = list(OAuth2Constants.CODE, OIDCResponseType.NONE, OIDCResponseType.ID_TOKEN, OIDCResponseType.TOKEN, "id_token token", "code id_token", "code token", "code id_token token")
static final List< String >	DEFAULT_SUBJECT_TYPES_SUPPORTED = list("public", "pairwise")
static final List< String >	DEFAULT_RESPONSE_MODES_SUPPORTED = list("query", "fragment", "form_post")
static final List< String >	DEFAULT_CLIENT_AUTH_SIGNING_ALG_VALUES_SUPPORTED = list(Algorithm.RS256.toString())
static final List< String >	DEFAULT_CLAIMS_SUPPORTED = list("sub", "iss", IDToken.AUTH_TIME, IDToken.NAME, IDToken.GIVEN_NAME, IDToken.FAMILY_NAME, IDToken.PREFERRED_USERNAME, IDToken.EMAIL)
static final List< String >	DEFAULT_CLAIM_TYPES_SUPPORTED = list("normal")
static final List< String >	DEFAULT_CODE_CHALLENGE_METHODS_SUPPORTED = list(OAuth2Constants.PKCE_METHOD_PLAIN, OAuth2Constants.PKCE_METHOD_S256)

非公開メンバ関数
List< String >	getClientAuthMethodsSupported ()
List< String >	getSupportedSigningAlgorithms (boolean includeNone)

静的非公開メンバ関数
static List< String >	list (String... values)

非公開変数類
KeycloakSession	session

詳解

著者

Stian Thorgersen

構築子と解体子

OIDCWellKnownProvider()

org.keycloak.protocol.oidc.OIDCWellKnownProvider.OIDCWellKnownProvider ( KeycloakSession  session )

inline

                                                          {
        this.session = session;
    }

関数詳解

close()

void org.keycloak.protocol.oidc.OIDCWellKnownProvider.close ( )

inline

org.keycloak.provider.Providerを実装しています。

                        {
    }

getClientAuthMethodsSupported()

List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.getClientAuthMethodsSupported ( )

inlineprivate

                                                         {
        List<String> result = new LinkedList<>();

        List<ProviderFactory> providerFactories = session.getKeycloakSessionFactory().getProviderFactories(ClientAuthenticator.class);
        for (ProviderFactory factory : providerFactories) {
            ClientAuthenticatorFactory clientAuthFactory = (ClientAuthenticatorFactory) factory;
            result.addAll(clientAuthFactory.getProtocolAuthenticatorMethods(OIDCLoginProtocol.LOGIN_PROTOCOL));
        }

        return result;
    }

getConfig()

Object org.keycloak.protocol.oidc.OIDCWellKnownProvider.getConfig ( )

inline

org.keycloak.wellknown.WellKnownProviderを実装しています。

                              {
        UriInfo uriInfo = session.getContext().getUri();
        RealmModel realm = session.getContext().getRealm();

        UriBuilder uriBuilder = RealmsResource.protocolUrl(uriInfo);

        OIDCConfigurationRepresentation config = new OIDCConfigurationRepresentation();
        config.setIssuer(Urls.realmIssuer(uriInfo.getBaseUri(), realm.getName()));
        config.setAuthorizationEndpoint(uriBuilder.clone().path(OIDCLoginProtocolService.class, "auth").build(realm.getName(), OIDCLoginProtocol.LOGIN_PROTOCOL).toString());
        config.setTokenEndpoint(uriBuilder.clone().path(OIDCLoginProtocolService.class, "token").build(realm.getName(), OIDCLoginProtocol.LOGIN_PROTOCOL).toString());
        config.setTokenIntrospectionEndpoint(uriBuilder.clone().path(OIDCLoginProtocolService.class, "token").path(TokenEndpoint.class, "introspect").build(realm.getName(), OIDCLoginProtocol.LOGIN_PROTOCOL).toString());
        config.setUserinfoEndpoint(uriBuilder.clone().path(OIDCLoginProtocolService.class, "issueUserInfo").build(realm.getName(), OIDCLoginProtocol.LOGIN_PROTOCOL).toString());
        config.setLogoutEndpoint(uriBuilder.clone().path(OIDCLoginProtocolService.class, "logout").build(realm.getName(), OIDCLoginProtocol.LOGIN_PROTOCOL).toString());
        config.setJwksUri(uriBuilder.clone().path(OIDCLoginProtocolService.class, "certs").build(realm.getName(), OIDCLoginProtocol.LOGIN_PROTOCOL).toString());
        config.setCheckSessionIframe(uriBuilder.clone().path(OIDCLoginProtocolService.class, "getLoginStatusIframe").build(realm.getName(), OIDCLoginProtocol.LOGIN_PROTOCOL).toString());
        config.setRegistrationEndpoint(RealmsResource.clientRegistrationUrl(uriInfo).path(ClientRegistrationService.class, "provider").build(realm.getName(), OIDCClientRegistrationProviderFactory.ID).toString());

        config.setIdTokenSigningAlgValuesSupported(getSupportedSigningAlgorithms(false));
        config.setUserInfoSigningAlgValuesSupported(getSupportedSigningAlgorithms(true));
        config.setRequestObjectSigningAlgValuesSupported(DEFAULT_REQUEST_OBJECT_SIGNING_ALG_VALUES_SUPPORTED);
        config.setResponseTypesSupported(DEFAULT_RESPONSE_TYPES_SUPPORTED);
        config.setSubjectTypesSupported(DEFAULT_SUBJECT_TYPES_SUPPORTED);
        config.setResponseModesSupported(DEFAULT_RESPONSE_MODES_SUPPORTED);
        config.setGrantTypesSupported(DEFAULT_GRANT_TYPES_SUPPORTED);

        config.setTokenEndpointAuthMethodsSupported(getClientAuthMethodsSupported());
        config.setTokenEndpointAuthSigningAlgValuesSupported(DEFAULT_CLIENT_AUTH_SIGNING_ALG_VALUES_SUPPORTED);

        config.setClaimsSupported(DEFAULT_CLAIMS_SUPPORTED);
        config.setClaimTypesSupported(DEFAULT_CLAIM_TYPES_SUPPORTED);
        config.setClaimsParameterSupported(false);

        List<ClientScopeModel> scopes = realm.getClientScopes();
        List<String> scopeNames = new LinkedList<>();
        for (ClientScopeModel clientScope : scopes) {
            if (clientScope.getProtocol().equals(OIDCLoginProtocol.LOGIN_PROTOCOL)) {
                scopeNames.add(clientScope.getName());
            }
        }
        scopeNames.add(0, OAuth2Constants.SCOPE_OPENID);
        config.setScopesSupported(scopeNames);

        config.setRequestParameterSupported(true);
        config.setRequestUriParameterSupported(true);

        // KEYCLOAK-7451 OAuth Authorization Server Metadata for Proof Key for Code Exchange
        config.setCodeChallengeMethodsSupported(DEFAULT_CODE_CHALLENGE_METHODS_SUPPORTED);

        // KEYCLOAK-6771 Certificate Bound Token
        // https://tools.ietf.org/html/draft-ietf-oauth-mtls-08#section-6.2
        config.setTlsClientCertificateBoundAccessTokens(true);

        return config;
    }

getSupportedSigningAlgorithms()

List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.getSupportedSigningAlgorithms ( boolean  includeNone )

inlineprivate

                                                                            {
        List<String> result = new LinkedList<>();
        for (ProviderFactory s : session.getKeycloakSessionFactory().getProviderFactories(SignatureProvider.class)) {
            result.add(s.getId());
        }
        if (includeNone) {
            result.add("none");
        }
        return result;
    }

list()

static List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.list ( String...  values )

inlinestaticprivate

                                                       {
        List<String> s = new LinkedList<>();
        for (String v : values) {
            s.add(v);
        }
        return s;
    }

メンバ詳解

DEFAULT_CLAIM_TYPES_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_CLAIM_TYPES_SUPPORTED = list("normal")

static

DEFAULT_CLAIMS_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_CLAIMS_SUPPORTED = list("sub", "iss", IDToken.AUTH_TIME, IDToken.NAME, IDToken.GIVEN_NAME, IDToken.FAMILY_NAME, IDToken.PREFERRED_USERNAME, IDToken.EMAIL)

static

DEFAULT_CLIENT_AUTH_SIGNING_ALG_VALUES_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_CLIENT_AUTH_SIGNING_ALG_VALUES_SUPPORTED = list(Algorithm.RS256.toString())

static

DEFAULT_CODE_CHALLENGE_METHODS_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_CODE_CHALLENGE_METHODS_SUPPORTED = list(OAuth2Constants.PKCE_METHOD_PLAIN, OAuth2Constants.PKCE_METHOD_S256)

static

DEFAULT_GRANT_TYPES_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_GRANT_TYPES_SUPPORTED = list(OAuth2Constants.AUTHORIZATION_CODE, OAuth2Constants.IMPLICIT, OAuth2Constants.REFRESH_TOKEN, OAuth2Constants.PASSWORD, OAuth2Constants.CLIENT_CREDENTIALS)

static

DEFAULT_REQUEST_OBJECT_SIGNING_ALG_VALUES_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_REQUEST_OBJECT_SIGNING_ALG_VALUES_SUPPORTED = list(Algorithm.none.toString(), Algorithm.RS256.toString())

static

DEFAULT_RESPONSE_MODES_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_RESPONSE_MODES_SUPPORTED = list("query", "fragment", "form_post")

static

DEFAULT_RESPONSE_TYPES_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_RESPONSE_TYPES_SUPPORTED = list(OAuth2Constants.CODE, OIDCResponseType.NONE, OIDCResponseType.ID_TOKEN, OIDCResponseType.TOKEN, "id_token token", "code id_token", "code token", "code id_token token")

static

DEFAULT_SUBJECT_TYPES_SUPPORTED

final List<String> org.keycloak.protocol.oidc.OIDCWellKnownProvider.DEFAULT_SUBJECT_TYPES_SUPPORTED = list("public", "pairwise")

static

session

KeycloakSession org.keycloak.protocol.oidc.OIDCWellKnownProvider.session

private

---

このクラス詳解は次のファイルから抽出されました:

• D:/AppData/doxygen/keycloak/oidc-service/src/main/java/org/keycloak/protocol/oidc/OIDCWellKnownProvider.java
