org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper クラス

org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper の継承関係図

org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper 連携図

公開メンバ関数
List< ProviderConfigProperty >	getConfigProperties ()
String	getId ()
String	getDisplayType ()
String	getDisplayCategory ()
String	getHelpText ()
String	getProtocol ()
void	close ()
final ProtocolMapper	create (KeycloakSession session)
void	init (Config.Scope config)
void	postInit (KeycloakSessionFactory factory)
AccessToken	transformUserInfoToken (AccessToken token, ProtocolMapperModel mappingModel, KeycloakSession session, UserSessionModel userSession, AuthenticatedClientSessionModel clientSession)
AccessToken	transformUserInfoToken (AccessToken token, ProtocolMapperModel mappingModel, KeycloakSession session, UserSessionModel userSession, AuthenticatedClientSessionModel clientSession)
AccessToken	transformAccessToken (AccessToken token, ProtocolMapperModel mappingModel, KeycloakSession session, UserSessionModel userSession, AuthenticatedClientSessionModel clientSession)
AccessToken	transformAccessToken (AccessToken token, ProtocolMapperModel mappingModel, KeycloakSession session, UserSessionModel userSession, AuthenticatedClientSessionModel clientSession)
IDToken	transformIDToken (IDToken token, ProtocolMapperModel mappingModel, KeycloakSession session, UserSessionModel userSession, AuthenticatedClientSessionModel clientSession)
IDToken	transformIDToken (IDToken token, ProtocolMapperModel mappingModel, KeycloakSession session, UserSessionModel userSession, AuthenticatedClientSessionModel clientSession)
default void	validateConfig (KeycloakSession session, RealmModel realm, ProtocolMapperContainerModel client, ProtocolMapperModel mapperModel) throws ProtocolMapperConfigException
default int	order ()

静的公開メンバ関数
static ProtocolMapperModel	create (String clientId, String clientRolePrefix, String name, String tokenClaimName, boolean accessToken, boolean idToken)
static ProtocolMapperModel	create (String clientId, String clientRolePrefix, String name, String tokenClaimName, boolean accessToken, boolean idToken, boolean multiValued)
static Stream< RoleModel >	getAllUserRolesStream (UserModel user)

静的公開変数類
static final String	PROVIDER_ID = "oidc-usermodel-client-role-mapper"
static final String	TOKEN_MAPPER_CATEGORY = "Token mapper"

限定公開メンバ関数
void	setClaim (IDToken token, ProtocolMapperModel mappingModel, UserSessionModel userSession)
void	setClaim (IDToken token, ProtocolMapperModel mappingModel, UserSessionModel userSession, KeycloakSession keycloakSession)

静的限定公開メンバ関数
static void	setClaim (IDToken token, ProtocolMapperModel mappingModel, UserSessionModel userSession, Predicate< RoleModel > restriction, String prefix)

静的関数
	[static initializer]

静的非公開メンバ関数
static Predicate< RoleModel >	getClientRoleFilter (String clientId, UserSessionModel userSession)

静的非公開変数類
static final List< ProviderConfigProperty >	CONFIG_PROPERTIES = new ArrayList<>()

詳解

Allows mapping of user client role mappings to an ID and Access Token claim.

著者

Thomas Darimont

関数詳解

[static initializer]()

org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.[static initializer] ( )

inlinestaticpackage

close()

void org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.close ( )

inlineinherited

org.keycloak.provider.Providerを実装しています。

                        {

    }

create() [1/3]

final ProtocolMapper org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.create ( KeycloakSession  session )

inlineinherited

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                                                                {
        throw new RuntimeException("UNSUPPORTED METHOD");
    }

create() [2/3]

static ProtocolMapperModel org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.create ( String  clientId, String  clientRolePrefix, String  name, String  tokenClaimName, boolean  accessToken, boolean  idToken  )

inlinestatic

                                                                                   {
        return create(clientId, clientRolePrefix, name, tokenClaimName, accessToken, idToken, false);

    }

create() [3/3]

static ProtocolMapperModel org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.create ( String  clientId, String  clientRolePrefix, String  name, String  tokenClaimName, boolean  accessToken, boolean  idToken, boolean  multiValued  )

inlinestatic

                                                                                                        {
        ProtocolMapperModel mapper = OIDCAttributeMapperHelper.createClaimMapper(name, "foo",
                tokenClaimName, "String",
                accessToken, idToken,
                PROVIDER_ID);

        mapper.getConfig().put(ProtocolMapperUtils.MULTIVALUED, String.valueOf(multiValued));
        mapper.getConfig().put(ProtocolMapperUtils.USER_MODEL_CLIENT_ROLE_MAPPING_CLIENT_ID, clientId);
        mapper.getConfig().put(ProtocolMapperUtils.USER_MODEL_CLIENT_ROLE_MAPPING_ROLE_PREFIX, clientRolePrefix);
        return mapper;
    }

getAllUserRolesStream()

static Stream<RoleModel> org.keycloak.protocol.oidc.mappers.AbstractUserRoleMappingMapper.getAllUserRolesStream ( UserModel  user )

inlinestaticinherited

Returns a stream with roles that come from:

• Direct assignment of the role to the user
• Direct assignment of the role to any group of the user or any of its parent group
• Composite roles are expanded recursively, the composite role itself is also contained in the returned stream

引数

user	User to enumerate the roles for

戻り値

                                                                          {
        return Stream.concat(
          user.getRoleMappings().stream(),
          user.getGroups().stream()
            .flatMap(g -> groupAndItsParentsStream(g))
            .flatMap(g -> g.getRoleMappings().stream()))
          .flatMap(RoleUtils::expandCompositeRolesStream);
    }

getClientRoleFilter()

static Predicate<RoleModel> org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.getClientRoleFilter ( String  clientId, UserSessionModel  userSession  )

inlinestaticprivate

                                                                                                           {
        if (clientId == null) {
            return RoleModel::isClientRole;
        }

        RealmModel clientRealm = userSession.getRealm();
        ClientModel client = clientRealm.getClientByClientId(clientId.trim());

        if (client == null) {
            return RoleModel::isClientRole;
        }

        boolean fullScopeAllowed = client.isFullScopeAllowed();
        Set<RoleModel> clientRoleMappings = client.getRoles();
        if (fullScopeAllowed) {
            return clientRoleMappings::contains;
        }

        Set<RoleModel> scopeMappings = new HashSet<>();

        // Add scope mappings of current client + all clientScopes of this client (including optional scopes if scope parameter matches)
        String scopeParam = null;
        AuthenticatedClientSessionModel authClientSession = userSession.getAuthenticatedClientSessionByClient(client.getId());
        if (authClientSession != null) {
            scopeParam = authClientSession.getNote(OAuth2Constants.SCOPE);
        }

        Set<ClientScopeModel> clientScopes = TokenManager.getRequestedClientScopes(scopeParam, client);
        for (ClientScopeModel clientScope : clientScopes) {
            scopeMappings.addAll(clientScope.getScopeMappings());
        }

        return role -> clientRoleMappings.contains(role) && scopeMappings.contains(role);
    }

getConfigProperties()

List<ProviderConfigProperty> org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.getConfigProperties ( )

inline

org.keycloak.provider.ConfiguredProviderを実装しています。

                                                              {
        return CONFIG_PROPERTIES;
    }

getDisplayCategory()

String org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.getDisplayCategory ( )

inline

org.keycloak.protocol.ProtocolMapperを実装しています。

                                       {
        return TOKEN_MAPPER_CATEGORY;
    }

getDisplayType()

String org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.getDisplayType ( )

inline

org.keycloak.protocol.ProtocolMapperを実装しています。

                                   {
        return "User Client Role";
    }

getHelpText()

String org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.getHelpText ( )

inline

org.keycloak.provider.ConfiguredProviderを実装しています。

                                {
        return "Map a user client role to a token claim.";
    }

getId()

String org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.getId ( )

inline

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                          {
        return PROVIDER_ID;
    }

getProtocol()

String org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.getProtocol ( )

inlineinherited

org.keycloak.protocol.ProtocolMapperを実装しています。

                                {
        return OIDCLoginProtocol.LOGIN_PROTOCOL;
    }

init()

void org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.init ( Config.Scope  config )

inlineinherited

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                                          {
    }

order()

default int org.keycloak.provider.ProviderFactory< T extends Provider >.order ( )

inlineinherited

org.keycloak.urls.HostnameProviderFactory, org.keycloak.protocol.oidc.ext.OIDCExtProviderFactoryで実装されています。

                        {
        return 0;
    }

postInit()

void org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.postInit ( KeycloakSessionFactory  factory )

inlineinherited

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                                                         {

    }

setClaim() [1/3]

static void org.keycloak.protocol.oidc.mappers.AbstractUserRoleMappingMapper.setClaim ( IDToken  token, ProtocolMapperModel  mappingModel, UserSessionModel  userSession, Predicate< RoleModel >  restriction, String  prefix  )

inlinestaticprotectedinherited

Retrieves all roles of the current user based on direct roles set to the user, its groups and their parent groups. Then it recursively expands all composite roles, and restricts according to the given predicate

restriction

. If the current client sessions is restricted (i.e. no client found in active user session has full scope allowed), the final list of roles is also restricted by the client scope. Finally, the list is mapped to the token into a claim.

引数

token
mappingModel
userSession
restriction
prefix

                                                       {
        String rolePrefix = prefix == null ? "" : prefix;
        UserModel user = userSession.getUser();

        // get a set of all realm roles assigned to the user or its group
        Stream<RoleModel> clientUserRoles = getAllUserRolesStream(user).filter(restriction);

        boolean dontLimitScope = userSession.getAuthenticatedClientSessions().values().stream().anyMatch(cs -> cs.getClient().isFullScopeAllowed());
        if (! dontLimitScope) {
            Set<RoleModel> clientRoles = userSession.getAuthenticatedClientSessions().values().stream()
              .flatMap(cs -> cs.getClient().getScopeMappings().stream())
              .collect(Collectors.toSet());

            clientUserRoles = clientUserRoles.filter(clientRoles::contains);
        }

        List<String> realmRoleNames = clientUserRoles
          .map(m -> rolePrefix + m.getName())
          .collect(Collectors.toList());

        Object claimValue = realmRoleNames;

        boolean multiValued = "true".equals(mappingModel.getConfig().get(ProtocolMapperUtils.MULTIVALUED));
        if (!multiValued) {
            claimValue = realmRoleNames.toString();
        }

        OIDCAttributeMapperHelper.mapClaim(token, mappingModel, claimValue);
    }

setClaim() [2/3]

void org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.setClaim ( IDToken  token, ProtocolMapperModel  mappingModel, UserSessionModel  userSession  )

inlineprotected

                                                                                                           {
        String clientId = mappingModel.getConfig().get(ProtocolMapperUtils.USER_MODEL_CLIENT_ROLE_MAPPING_CLIENT_ID);
        String rolePrefix = mappingModel.getConfig().get(ProtocolMapperUtils.USER_MODEL_CLIENT_ROLE_MAPPING_ROLE_PREFIX);

        setClaim(token, mappingModel, userSession, getClientRoleFilter(clientId, userSession), rolePrefix);
    }

setClaim() [3/3]

void org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.setClaim ( IDToken  token, ProtocolMapperModel  mappingModel, UserSessionModel  userSession, KeycloakSession  keycloakSession  )

inlineprotectedinherited

Intended to be overridden in ProtocolMapper implementations to add claims to an token.

引数

token
mappingModel
userSession
keycloakSession

                                                                                                                                            {
        // we delegate to the old #setClaim(...) method for backwards compatibility
        setClaim(token, mappingModel, userSession);
    }

transformAccessToken() [1/2]

AccessToken org.keycloak.protocol.oidc.mappers.OIDCAccessTokenMapper.transformAccessToken ( AccessToken  token, ProtocolMapperModel  mappingModel, KeycloakSession  session, UserSessionModel  userSession, AuthenticatedClientSessionModel  clientSession  )

inherited

org.keycloak.protocol.oidc.mappers.RoleNameMapper, org.keycloak.protocol.oidc.mappers.HardcodedRole, org.keycloak.protocol.oidc.mappers.AbstractPairwiseSubMapperで実装されています。

transformAccessToken() [2/2]

AccessToken org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.transformAccessToken ( AccessToken  token, ProtocolMapperModel  mappingModel, KeycloakSession  session, UserSessionModel  userSession, AuthenticatedClientSessionModel  clientSession  )

inlineinherited

                                                                                                                         {

        if (!OIDCAttributeMapperHelper.includeInAccessToken(mappingModel)){
            return token;
        }

        setClaim(token, mappingModel, userSession, session);
        return token;
    }

transformIDToken() [1/2]

IDToken org.keycloak.protocol.oidc.mappers.OIDCIDTokenMapper.transformIDToken ( IDToken  token, ProtocolMapperModel  mappingModel, KeycloakSession  session, UserSessionModel  userSession, AuthenticatedClientSessionModel  clientSession  )

inherited

org.keycloak.protocol.oidc.mappers.AbstractPairwiseSubMapperで実装されています。

transformIDToken() [2/2]

IDToken org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.transformIDToken ( IDToken  token, ProtocolMapperModel  mappingModel, KeycloakSession  session, UserSessionModel  userSession, AuthenticatedClientSessionModel  clientSession  )

inlineinherited

                                                                                                                 {

        if (!OIDCAttributeMapperHelper.includeInIDToken(mappingModel)){
            return token;
        }

        setClaim(token, mappingModel, userSession, session);
        return token;
    }

transformUserInfoToken() [1/2]

AccessToken org.keycloak.protocol.oidc.mappers.UserInfoTokenMapper.transformUserInfoToken ( AccessToken  token, ProtocolMapperModel  mappingModel, KeycloakSession  session, UserSessionModel  userSession, AuthenticatedClientSessionModel  clientSession  )

inherited

org.keycloak.protocol.oidc.mappers.AbstractPairwiseSubMapperで実装されています。

transformUserInfoToken() [2/2]

AccessToken org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.transformUserInfoToken ( AccessToken  token, ProtocolMapperModel  mappingModel, KeycloakSession  session, UserSessionModel  userSession, AuthenticatedClientSessionModel  clientSession  )

inlineinherited

                                                                                                                           {

        if (!OIDCAttributeMapperHelper.includeInUserInfo(mappingModel)) {
            return token;
        }

        setClaim(token, mappingModel, userSession, session);
        return token;
    }

validateConfig()

default void org.keycloak.protocol.ProtocolMapper.validateConfig ( KeycloakSession  session, RealmModel  realm, ProtocolMapperContainerModel  client, ProtocolMapperModel  mapperModel  ) throws ProtocolMapperConfigException

inlineinherited

Called when instance of mapperModel is created/updated for this protocolMapper through admin endpoint

引数

session
realm
client	client or clientTemplate
mapperModel

例外

ProtocolMapperConfigException

if configuration provided in mapperModel is not valid

org.keycloak.protocol.oidc.mappers.ScriptBasedOIDCProtocolMapper, org.keycloak.protocol.oidc.mappers.AbstractPairwiseSubMapperで実装されています。

                                                                                                                                                                                      {
    };

メンバ詳解

CONFIG_PROPERTIES

final List<ProviderConfigProperty> org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.CONFIG_PROPERTIES = new ArrayList<>()

staticprivate

PROVIDER_ID

final String org.keycloak.protocol.oidc.mappers.UserClientRoleMappingMapper.PROVIDER_ID = "oidc-usermodel-client-role-mapper"

static

TOKEN_MAPPER_CATEGORY

final String org.keycloak.protocol.oidc.mappers.AbstractOIDCProtocolMapper.TOKEN_MAPPER_CATEGORY = "Token mapper"

staticinherited

---

このクラス詳解は次のファイルから抽出されました:

• D:/AppData/doxygen/keycloak/oidc-service/src/main/java/org/keycloak/protocol/oidc/mappers/UserClientRoleMappingMapper.java
