org.keycloak.authentication.DefaultAuthenticationFlow クラス

org.keycloak.authentication.DefaultAuthenticationFlow の継承関係図

org.keycloak.authentication.DefaultAuthenticationFlow 連携図

公開メンバ関数
	DefaultAuthenticationFlow (AuthenticationProcessor processor, AuthenticationFlowModel flow)
Response	processAction (String actionExecution)
Response	processFlow ()
Response	processResult (AuthenticationProcessor.Result result, boolean isAction)
Response	sendChallenge (AuthenticationProcessor.Result result, AuthenticationExecutionModel execution)

公開変数類
String	BASIC_FLOW = "basic-flow"
String	FORM_FLOW = "form-flow"
String	CLIENT_FLOW = "client-flow"

限定公開メンバ関数
boolean	isProcessed (AuthenticationExecutionModel model)
Authenticator	createAuthenticator (AuthenticatorFactory factory)

変数
Response	alternativeChallenge = null
AuthenticationExecutionModel	challengedAlternativeExecution = null
boolean	alternativeSuccessful = false
List< AuthenticationExecutionModel >	executions
Iterator< AuthenticationExecutionModel >	executionIterator
AuthenticationProcessor	processor
AuthenticationFlowModel	flow

静的非公開変数類
static final Logger	logger = Logger.getLogger(DefaultAuthenticationFlow.class)

詳解

著者

Bill Burke

バージョン

Revision

1

構築子と解体子

DefaultAuthenticationFlow()

org.keycloak.authentication.DefaultAuthenticationFlow.DefaultAuthenticationFlow ( AuthenticationProcessor  processor, AuthenticationFlowModel  flow  )

inline

                                                                                                      {
        this.processor = processor;
        this.flow = flow;
        this.executions = processor.getRealm().getAuthenticationExecutions(flow.getId());
        this.executionIterator = executions.iterator();
    }

関数詳解

createAuthenticator()

Authenticator org.keycloak.authentication.DefaultAuthenticationFlow.createAuthenticator ( AuthenticatorFactory  factory )

inlineprotected

                                                                              {
        String display = processor.getAuthenticationSession().getAuthNote(OAuth2Constants.DISPLAY);
        if (display == null) return factory.create(processor.getSession());


        if (factory instanceof DisplayTypeAuthenticatorFactory) {
            Authenticator authenticator = ((DisplayTypeAuthenticatorFactory)factory).createDisplay(processor.getSession(), display);
            if (authenticator != null) return authenticator;
        }
        // todo create a provider for handling lack of display support
        if (OAuth2Constants.DISPLAY_CONSOLE.equalsIgnoreCase(display)) {
            processor.getAuthenticationSession().removeAuthNote(OAuth2Constants.DISPLAY);
            throw new AuthenticationFlowException(AuthenticationFlowError.DISPLAY_NOT_SUPPORTED,
                    ConsoleDisplayMode.browserContinue(processor.getSession(), processor.getRefreshUrl(true).toString()));

        } else {
            return factory.create(processor.getSession());
        }
    }

isProcessed()

boolean org.keycloak.authentication.DefaultAuthenticationFlow.isProcessed ( AuthenticationExecutionModel  model )

inlineprotected

                                                                      {
        if (model.isDisabled()) return true;
        AuthenticationSessionModel.ExecutionStatus status = processor.getAuthenticationSession().getExecutionStatus().get(model.getId());
        if (status == null) return false;
        return status == AuthenticationSessionModel.ExecutionStatus.SUCCESS || status == AuthenticationSessionModel.ExecutionStatus.SKIPPED
                || status == AuthenticationSessionModel.ExecutionStatus.ATTEMPTED
                || status == AuthenticationSessionModel.ExecutionStatus.SETUP_REQUIRED;
    }

processAction()

Response org.keycloak.authentication.DefaultAuthenticationFlow.processAction ( String  actionExecution )

inline

org.keycloak.authentication.AuthenticationFlowを実装しています。

                                                          {
        logger.debugv("processAction: {0}", actionExecution);
        while (executionIterator.hasNext()) {
            AuthenticationExecutionModel model = executionIterator.next();
            logger.debugv("check: {0} requirement: {1}", model.getAuthenticator(), model.getRequirement().toString());
            if (isProcessed(model)) {
                logger.debug("execution is processed");
                if (!alternativeSuccessful && model.isAlternative() && processor.isSuccessful(model))
                    alternativeSuccessful = true;
                continue;
            }
            if (model.isAuthenticatorFlow()) {
                AuthenticationFlow authenticationFlow = processor.createFlowExecution(model.getFlowId(), model);
                Response flowChallenge = authenticationFlow.processAction(actionExecution);
                if (flowChallenge == null) {
                    processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.SUCCESS);
                    if (model.isAlternative()) alternativeSuccessful = true;
                    return processFlow();
                } else {
                   return flowChallenge;
                }
            } else if (model.getId().equals(actionExecution)) {
                AuthenticatorFactory factory = (AuthenticatorFactory) processor.getSession().getKeycloakSessionFactory().getProviderFactory(Authenticator.class, model.getAuthenticator());
                if (factory == null) {
                    throw new RuntimeException("Unable to find factory for AuthenticatorFactory: " + model.getAuthenticator() + " did you forget to declare it in a META-INF/services file?");
                }
                Authenticator authenticator = createAuthenticator(factory);
                AuthenticationProcessor.Result result = processor.createAuthenticatorContext(model, authenticator, executions);
                logger.debugv("action: {0}", model.getAuthenticator());
                authenticator.action(result);
                Response response = processResult(result, true);
                if (response == null) {
                    processor.getAuthenticationSession().removeAuthNote(AuthenticationProcessor.CURRENT_AUTHENTICATION_EXECUTION);
                    return processFlow();
                } else return response;
            }
        }
        throw new AuthenticationFlowException("action is not in current execution", AuthenticationFlowError.INTERNAL_ERROR);
    }

processFlow()

Response org.keycloak.authentication.DefaultAuthenticationFlow.processFlow ( )

inline

org.keycloak.authentication.AuthenticationFlowを実装しています。

                                  {
        logger.debug("processFlow");
        while (executionIterator.hasNext()) {
            AuthenticationExecutionModel model = executionIterator.next();
            logger.debugv("check execution: {0} requirement: {1}", model.getAuthenticator(), model.getRequirement().toString());

            if (isProcessed(model)) {
                logger.debug("execution is processed");
                if (!alternativeSuccessful && model.isAlternative() && processor.isSuccessful(model))
                    alternativeSuccessful = true;
                continue;
            }
            if (model.isAlternative() && alternativeSuccessful) {
                logger.debug("Skip alternative execution");
                processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.SKIPPED);
                continue;
            }
            if (model.isAuthenticatorFlow()) {
                logger.debug("execution is flow");
                AuthenticationFlow authenticationFlow = processor.createFlowExecution(model.getFlowId(), model);

                Response flowChallenge = null;
                try {
                    flowChallenge = authenticationFlow.processFlow();
                } catch (AuthenticationFlowException afe) {
                    if (model.isAlternative()) {
                        logger.debug("Thrown exception in alternative Subflow. Ignoring Subflow");
                        processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.ATTEMPTED);
                        continue;
                    } else {
                        throw afe;
                    }
                }

                if (flowChallenge == null) {
                    processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.SUCCESS);
                    if (model.isAlternative()) alternativeSuccessful = true;
                    continue;
                } else {
                    if (model.isAlternative()) {
                        alternativeChallenge = flowChallenge;
                        challengedAlternativeExecution = model;
                    } else if (model.isRequired()) {
                        processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.CHALLENGED);
                        return flowChallenge;
                    } else if (model.isOptional()) {
                        processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.SKIPPED);
                        continue;
                    } else {
                        processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.SKIPPED);
                        continue;
                    }
                    return flowChallenge;
                }
            }

            AuthenticatorFactory factory = (AuthenticatorFactory) processor.getSession().getKeycloakSessionFactory().getProviderFactory(Authenticator.class, model.getAuthenticator());
            if (factory == null) {
                throw new RuntimeException("Unable to find factory for AuthenticatorFactory: " + model.getAuthenticator() + " did you forget to declare it in a META-INF/services file?");
            }
            Authenticator authenticator = createAuthenticator(factory);
            logger.debugv("authenticator: {0}", factory.getId());
            UserModel authUser = processor.getAuthenticationSession().getAuthenticatedUser();

            if (authenticator.requiresUser() && authUser == null) {
                if (alternativeChallenge != null) {
                    processor.getAuthenticationSession().setExecutionStatus(challengedAlternativeExecution.getId(), AuthenticationSessionModel.ExecutionStatus.CHALLENGED);
                    return alternativeChallenge;
                }
                throw new AuthenticationFlowException("authenticator: " + factory.getId(), AuthenticationFlowError.UNKNOWN_USER);
            }
            boolean configuredFor = false;
            if (authenticator.requiresUser() && authUser != null) {
                configuredFor = authenticator.configuredFor(processor.getSession(), processor.getRealm(), authUser);
                if (!configuredFor) {
                    if (model.isRequired()) {
                        if (factory.isUserSetupAllowed()) {
                            logger.debugv("authenticator SETUP_REQUIRED: {0}", factory.getId());
                            processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.SETUP_REQUIRED);
                            authenticator.setRequiredActions(processor.getSession(), processor.getRealm(), processor.getAuthenticationSession().getAuthenticatedUser());
                            continue;
                        } else {
                            throw new AuthenticationFlowException(AuthenticationFlowError.CREDENTIAL_SETUP_REQUIRED);
                        }
                    } else if (model.isOptional()) {
                        processor.getAuthenticationSession().setExecutionStatus(model.getId(), AuthenticationSessionModel.ExecutionStatus.SKIPPED);
                        continue;
                    }
                }
            }
            // skip if action as successful already
//            Response redirect = processor.checkWasSuccessfulBrowserAction();
//            if (redirect != null) return redirect;

            AuthenticationProcessor.Result context = processor.createAuthenticatorContext(model, authenticator, executions);
            logger.debugv("invoke authenticator.authenticate: {0}", factory.getId());
            authenticator.authenticate(context);
            Response response = processResult(context, false);
            if (response != null) return response;
        }
        return null;
    }

processResult()

Response org.keycloak.authentication.DefaultAuthenticationFlow.processResult ( AuthenticationProcessor.Result  result, boolean  isAction  )

inline

                                                                                           {
        AuthenticationExecutionModel execution = result.getExecution();
        FlowStatus status = result.getStatus();
        switch (status) {
            case SUCCESS:
                logger.debugv("authenticator SUCCESS: {0}", execution.getAuthenticator());
                processor.getAuthenticationSession().setExecutionStatus(execution.getId(), AuthenticationSessionModel.ExecutionStatus.SUCCESS);
                if (execution.isAlternative()) alternativeSuccessful = true;
                return null;
            case FAILED:
                logger.debugv("authenticator FAILED: {0}", execution.getAuthenticator());
                processor.logFailure();
                processor.getAuthenticationSession().setExecutionStatus(execution.getId(), AuthenticationSessionModel.ExecutionStatus.FAILED);
                if (result.getChallenge() != null) {
                    return sendChallenge(result, execution);
                }
                throw new AuthenticationFlowException(result.getError());
            case FORK:
                logger.debugv("reset browser login from authenticator: {0}", execution.getAuthenticator());
                processor.getAuthenticationSession().setAuthNote(AuthenticationProcessor.CURRENT_AUTHENTICATION_EXECUTION, execution.getId());
                throw new ForkFlowException(result.getSuccessMessage(), result.getErrorMessage());
            case FORCE_CHALLENGE:
                processor.getAuthenticationSession().setExecutionStatus(execution.getId(), AuthenticationSessionModel.ExecutionStatus.CHALLENGED);
                return sendChallenge(result, execution);
            case CHALLENGE:
                logger.debugv("authenticator CHALLENGE: {0}", execution.getAuthenticator());
                if (execution.isRequired()) {
                    processor.getAuthenticationSession().setExecutionStatus(execution.getId(), AuthenticationSessionModel.ExecutionStatus.CHALLENGED);
                    return sendChallenge(result, execution);
                }
                UserModel authenticatedUser = processor.getAuthenticationSession().getAuthenticatedUser();
                if (execution.isOptional() && authenticatedUser != null && result.getAuthenticator().configuredFor(processor.getSession(), processor.getRealm(), authenticatedUser)) {
                    processor.getAuthenticationSession().setExecutionStatus(execution.getId(), AuthenticationSessionModel.ExecutionStatus.CHALLENGED);
                    return sendChallenge(result, execution);
                }
                if (execution.isAlternative()) {
                    alternativeChallenge = result.getChallenge();
                    challengedAlternativeExecution = execution;
                } else {
                    processor.getAuthenticationSession().setExecutionStatus(execution.getId(), AuthenticationSessionModel.ExecutionStatus.SKIPPED);
                }
                return null;
            case FAILURE_CHALLENGE:
                logger.debugv("authenticator FAILURE_CHALLENGE: {0}", execution.getAuthenticator());
                processor.logFailure();
                processor.getAuthenticationSession().setExecutionStatus(execution.getId(), AuthenticationSessionModel.ExecutionStatus.CHALLENGED);
                return sendChallenge(result, execution);
            case ATTEMPTED:
                logger.debugv("authenticator ATTEMPTED: {0}", execution.getAuthenticator());
                if (execution.getRequirement() == AuthenticationExecutionModel.Requirement.REQUIRED) {
                    throw new AuthenticationFlowException(AuthenticationFlowError.INVALID_CREDENTIALS);
                }
                processor.getAuthenticationSession().setExecutionStatus(execution.getId(), AuthenticationSessionModel.ExecutionStatus.ATTEMPTED);
                return null;
            case FLOW_RESET:
                processor.resetFlow();
                return processor.authenticate();
            default:
                logger.debugv("authenticator INTERNAL_ERROR: {0}", execution.getAuthenticator());
                ServicesLogger.LOGGER.unknownResultStatus();
                throw new AuthenticationFlowException(AuthenticationFlowError.INTERNAL_ERROR);
        }
    }

sendChallenge()

Response org.keycloak.authentication.DefaultAuthenticationFlow.sendChallenge ( AuthenticationProcessor.Result  result, AuthenticationExecutionModel  execution  )

inline

                                                                                                                 {
        processor.getAuthenticationSession().setAuthNote(AuthenticationProcessor.CURRENT_AUTHENTICATION_EXECUTION, execution.getId());
        return result.getChallenge();
    }

メンバ詳解

alternativeChallenge

Response org.keycloak.authentication.DefaultAuthenticationFlow.alternativeChallenge = null

package

alternativeSuccessful

boolean org.keycloak.authentication.DefaultAuthenticationFlow.alternativeSuccessful = false

package

BASIC_FLOW

String org.keycloak.authentication.AuthenticationFlow.BASIC_FLOW = "basic-flow"

inherited

challengedAlternativeExecution

AuthenticationExecutionModel org.keycloak.authentication.DefaultAuthenticationFlow.challengedAlternativeExecution = null

package

CLIENT_FLOW

String org.keycloak.authentication.AuthenticationFlow.CLIENT_FLOW = "client-flow"

inherited

executionIterator

Iterator<AuthenticationExecutionModel> org.keycloak.authentication.DefaultAuthenticationFlow.executionIterator

package

executions

List<AuthenticationExecutionModel> org.keycloak.authentication.DefaultAuthenticationFlow.executions

package

flow

AuthenticationFlowModel org.keycloak.authentication.DefaultAuthenticationFlow.flow

package

FORM_FLOW

String org.keycloak.authentication.AuthenticationFlow.FORM_FLOW = "form-flow"

inherited

logger

final Logger org.keycloak.authentication.DefaultAuthenticationFlow.logger = Logger.getLogger(DefaultAuthenticationFlow.class)

staticprivate

processor

AuthenticationProcessor org.keycloak.authentication.DefaultAuthenticationFlow.processor

package

---

このクラス詳解は次のファイルから抽出されました:

• D:/AppData/doxygen/keycloak/src/keycloak/src/main/java/org/keycloak/authentication/DefaultAuthenticationFlow.java
