org.keycloak.adapters.OAuthRequestAuthenticator クラス

org.keycloak.adapters.OAuthRequestAuthenticator 連携図

公開メンバ関数
	OAuthRequestAuthenticator (RequestAuthenticator requestAuthenticator, HttpFacade facade, KeycloakDeployment deployment, int sslRedirectPort, AdapterSessionStore tokenStore)
AuthChallenge	getChallenge ()
String	getTokenString ()
AccessToken	getToken ()
String	getRefreshToken ()
String	getIdTokenString ()
void	setIdTokenString (String idTokenString)
IDToken	getIdToken ()
void	setIdToken (IDToken idToken)
String	getStrippedOauthParametersRequestUri ()
void	setStrippedOauthParametersRequestUri (String strippedOauthParametersRequestUri)
AuthOutcome	authenticate ()

限定公開メンバ関数
String	getRequestUrl ()
boolean	isRequestSecure ()
OIDCHttpFacade.Cookie	getCookie (String cookieName)
String	getCookieValue (String cookieName)
String	getQueryParamValue (String paramName)
String	getError ()
String	getCode ()
String	getRedirectUri (String state)
int	sslRedirectPort ()
String	getStateCode ()
AuthChallenge	loginRedirect ()
AuthChallenge	checkStateCookie ()
AuthChallenge	challenge (final int code, final OIDCAuthenticationError.Reason reason, final String description)
AuthChallenge	resolveCode (String code)
String	stripOauthParametersFromRedirect ()

限定公開変数類
KeycloakDeployment	deployment
RequestAuthenticator	reqAuthenticator
int	sslRedirectPort
AdapterSessionStore	tokenStore
String	tokenString
String	idTokenString
IDToken	idToken
AccessToken	token
HttpFacade	facade
AuthChallenge	challenge
String	refreshToken
String	strippedOauthParametersRequestUri

非公開メンバ関数
String	rewrittenRedirectUri (String originalUri)
void	logToken (String name, String token)

静的非公開変数類
static final Logger	log = Logger.getLogger(OAuthRequestAuthenticator.class)

詳解

著者

Bill Burke

バージョン

Revision

1

構築子と解体子

OAuthRequestAuthenticator()

org.keycloak.adapters.OAuthRequestAuthenticator.OAuthRequestAuthenticator ( RequestAuthenticator  requestAuthenticator, HttpFacade  facade, KeycloakDeployment  deployment, int  sslRedirectPort, AdapterSessionStore  tokenStore  )

inline

                                                                                                                                                                                       {
        this.reqAuthenticator = requestAuthenticator;
        this.facade = facade;
        this.deployment = deployment;
        this.sslRedirectPort = deployment.getConfidentialPort() != -1 ? deployment.getConfidentialPort() : sslRedirectPort;
        this.tokenStore = tokenStore;
    }

関数詳解

authenticate()

AuthOutcome org.keycloak.adapters.OAuthRequestAuthenticator.authenticate ( )

inline

                                      {
        String code = getCode();
        if (code == null) {
            log.debug("there was no code");
            String error = getError();
            if (error != null) {
                // todo how do we send a response?
                log.warn("There was an error: " + error);
                challenge = challenge(400, OIDCAuthenticationError.Reason.OAUTH_ERROR, error);
                return AuthOutcome.FAILED;
            } else {
                log.debug("redirecting to auth server");
                challenge = loginRedirect();
                return AuthOutcome.NOT_ATTEMPTED;
            }
        } else {
            log.debug("there was a code, resolving");
            challenge = resolveCode(code);
            if (challenge != null) {
                return AuthOutcome.FAILED;
            }
            return AuthOutcome.AUTHENTICATED;
        }

    }

challenge()

AuthChallenge org.keycloak.adapters.OAuthRequestAuthenticator.challenge ( final int  code, final OIDCAuthenticationError.Reason  reason, final String  description  )

inlineprotected

                                                                                                                             {
        return new AuthChallenge() {
            @Override
            public int getResponseCode() {
                return code;
            }

            @Override
            public boolean challenge(HttpFacade exchange) {
                OIDCAuthenticationError error = new OIDCAuthenticationError(reason, description);
                exchange.getRequest().setError(error);
                exchange.getResponse().sendError(code);
                return true;
            }
        };
    }

checkStateCookie()

AuthChallenge org.keycloak.adapters.OAuthRequestAuthenticator.checkStateCookie ( )

inlineprotected

                                               {
        OIDCHttpFacade.Cookie stateCookie = getCookie(deployment.getStateCookieName());

        if (stateCookie == null) {
            log.warn("No state cookie");
            return challenge(400, OIDCAuthenticationError.Reason.INVALID_STATE_COOKIE, null);
        }
        // reset the cookie
        log.debug("** reseting application state cookie");
        facade.getResponse().resetCookie(deployment.getStateCookieName(), stateCookie.getPath());
        String stateCookieValue = getCookieValue(deployment.getStateCookieName());

        String state = getQueryParamValue(OAuth2Constants.STATE);
        if (state == null) {
            log.warn("state parameter was null");
            return challenge(400, OIDCAuthenticationError.Reason.INVALID_STATE_COOKIE, null);
        }
        if (!state.equals(stateCookieValue)) {
            log.warn("state parameter invalid");
            log.warn("cookie: " + stateCookieValue);
            log.warn("queryParam: " + state);
            return challenge(400, OIDCAuthenticationError.Reason.INVALID_STATE_COOKIE, null);
        }
        return null;

    }

getChallenge()

AuthChallenge org.keycloak.adapters.OAuthRequestAuthenticator.getChallenge ( )

inline

                                        {
        return challenge;
    }

getCode()

String org.keycloak.adapters.OAuthRequestAuthenticator.getCode ( )

inlineprotected

                               {
        return getQueryParamValue(OAuth2Constants.CODE);
    }

getCookie()

OIDCHttpFacade.Cookie org.keycloak.adapters.OAuthRequestAuthenticator.getCookie ( String  cookieName )

inlineprotected

                                                                 {
        return facade.getRequest().getCookie(cookieName);
    }

getCookieValue()

String org.keycloak.adapters.OAuthRequestAuthenticator.getCookieValue ( String  cookieName )

inlineprotected

                                                       {
        OIDCHttpFacade.Cookie cookie = getCookie(cookieName);
        if (cookie == null) return null;
        return cookie.getValue();
    }

getError()

String org.keycloak.adapters.OAuthRequestAuthenticator.getError ( )

inlineprotected

                                {
        return getQueryParamValue(OAuth2Constants.ERROR);
    }

getIdToken()

IDToken org.keycloak.adapters.OAuthRequestAuthenticator.getIdToken ( )

inline

                                {
        return idToken;
    }

getIdTokenString()

String org.keycloak.adapters.OAuthRequestAuthenticator.getIdTokenString ( )

inline

                                     {
        return idTokenString;
    }

getQueryParamValue()

String org.keycloak.adapters.OAuthRequestAuthenticator.getQueryParamValue ( String  paramName )

inlineprotected

                                                          {
        return facade.getRequest().getQueryParamValue(paramName);
    }

getRedirectUri()

String org.keycloak.adapters.OAuthRequestAuthenticator.getRedirectUri ( String  state )

inlineprotected

                                                  {
        String url = getRequestUrl();
        log.debugf("callback uri: %s", url);

        if (!facade.getRequest().isSecure() && deployment.getSslRequired().isRequired(facade.getRequest().getRemoteAddr())) {
            int port = sslRedirectPort();
            if (port < 0) {
                // disabled?
                return null;
            }
            KeycloakUriBuilder secureUrl = KeycloakUriBuilder.fromUri(url).scheme("https").port(-1);
            if (port != 443) secureUrl.port(port);
            url = secureUrl.build().toString();
        }

        String loginHint = getQueryParamValue("login_hint");
        url = UriUtils.stripQueryParam(url,"login_hint");

        String idpHint = getQueryParamValue(AdapterConstants.KC_IDP_HINT);
        url = UriUtils.stripQueryParam(url, AdapterConstants.KC_IDP_HINT);

        String scope = getQueryParamValue(OAuth2Constants.SCOPE);
        url = UriUtils.stripQueryParam(url, OAuth2Constants.SCOPE);

        String prompt = getQueryParamValue(OAuth2Constants.PROMPT);
        url = UriUtils.stripQueryParam(url, OAuth2Constants.PROMPT);

        String maxAge = getQueryParamValue(OAuth2Constants.MAX_AGE);
        url = UriUtils.stripQueryParam(url, OAuth2Constants.MAX_AGE);

        String uiLocales = getQueryParamValue(OAuth2Constants.UI_LOCALES_PARAM);
        url = UriUtils.stripQueryParam(url, OAuth2Constants.UI_LOCALES_PARAM);

        KeycloakUriBuilder redirectUriBuilder = deployment.getAuthUrl().clone()
                .queryParam(OAuth2Constants.RESPONSE_TYPE, OAuth2Constants.CODE)
                .queryParam(OAuth2Constants.CLIENT_ID, deployment.getResourceName())
                .queryParam(OAuth2Constants.REDIRECT_URI, rewrittenRedirectUri(url))
                .queryParam(OAuth2Constants.STATE, state)
                .queryParam("login", "true");
        if(loginHint != null && loginHint.length() > 0){
            redirectUriBuilder.queryParam("login_hint",loginHint);
        }
        if (idpHint != null && idpHint.length() > 0) {
            redirectUriBuilder.queryParam(AdapterConstants.KC_IDP_HINT,idpHint);
        }
        if (prompt != null && prompt.length() > 0) {
            redirectUriBuilder.queryParam(OAuth2Constants.PROMPT, prompt);
        }
        if (maxAge != null && maxAge.length() > 0) {
            redirectUriBuilder.queryParam(OAuth2Constants.MAX_AGE, maxAge);
        }
        if (uiLocales != null && uiLocales.length() > 0) {
            redirectUriBuilder.queryParam(OAuth2Constants.UI_LOCALES_PARAM, uiLocales);
        }

        scope = TokenUtil.attachOIDCScope(scope);
        redirectUriBuilder.queryParam(OAuth2Constants.SCOPE, scope);

        return redirectUriBuilder.build().toString();
    }

getRefreshToken()

String org.keycloak.adapters.OAuthRequestAuthenticator.getRefreshToken ( )

inline

                                    {
        return refreshToken;
    }

getRequestUrl()

String org.keycloak.adapters.OAuthRequestAuthenticator.getRequestUrl ( )

inlineprotected

                                     {
        return facade.getRequest().getURI();
    }

getStateCode()

String org.keycloak.adapters.OAuthRequestAuthenticator.getStateCode ( )

inlineprotected

                                    {
        return AdapterUtils.generateId();
    }

getStrippedOauthParametersRequestUri()

String org.keycloak.adapters.OAuthRequestAuthenticator.getStrippedOauthParametersRequestUri ( )

inline

                                                         {
        return strippedOauthParametersRequestUri;
    }

getToken()

AccessToken org.keycloak.adapters.OAuthRequestAuthenticator.getToken ( )

inline

                                  {
        return token;
    }

getTokenString()

String org.keycloak.adapters.OAuthRequestAuthenticator.getTokenString ( )

inline

                                   {
        return tokenString;
    }

isRequestSecure()

boolean org.keycloak.adapters.OAuthRequestAuthenticator.isRequestSecure ( )

inlineprotected

                                        {
        return facade.getRequest().isSecure();
    }

loginRedirect()

AuthChallenge org.keycloak.adapters.OAuthRequestAuthenticator.loginRedirect ( )

inlineprotected

                                            {
        final String state = getStateCode();
        final String redirect =  getRedirectUri(state);
        if (redirect == null) {
            return challenge(403, OIDCAuthenticationError.Reason.NO_REDIRECT_URI, null);
        }
        return new AuthChallenge() {

            @Override
            public int getResponseCode() {
                return 0;
            }

            @Override
            public boolean challenge(HttpFacade exchange) {
                tokenStore.saveRequest();
                log.debug("Sending redirect to login page: " + redirect);
                exchange.getResponse().setStatus(302);
                exchange.getResponse().setCookie(deployment.getStateCookieName(), state, /* need to set path? */ null, null, -1, deployment.getSslRequired().isRequired(facade.getRequest().getRemoteAddr()), true);
                exchange.getResponse().setHeader("Location", redirect);
                return true;
            }
        };
    }

logToken()

void org.keycloak.adapters.OAuthRequestAuthenticator.logToken ( String  name, String  token  )

inlineprivate

                                                     {
        try {
            JWSInput jwsInput = new JWSInput(token);
            String wireString = jwsInput.getWireString();
            log.tracef("\t%s: %s", name, wireString.substring(0, wireString.lastIndexOf(".")) + ".signature");
        } catch (JWSInputException e) {
            log.errorf(e, "Failed to parse %s: %s", name, token);
        }
    }

resolveCode()

AuthChallenge org.keycloak.adapters.OAuthRequestAuthenticator.resolveCode ( String  code )

inlineprotected

Start or continue the oauth login process.

if code query parameter is not present, then browser is redirected to authUrl. The redirect URL will be the URL of the current request.

If code query parameter is present, then an access token is obtained by invoking a secure request to the codeUrl. If the access token is obtained, the browser is again redirected to the current request URL, but any OAuth protocol specific query parameters are removed.

戻り値

null if an access token was obtained, otherwise a challenge is returned

                                                     {
        // abort if not HTTPS
        if (!isRequestSecure() && deployment.getSslRequired().isRequired(facade.getRequest().getRemoteAddr())) {
            log.error("Adapter requires SSL. Request: " + facade.getRequest().getURI());
            return challenge(403, OIDCAuthenticationError.Reason.SSL_REQUIRED, null);
        }

        log.debug("checking state cookie for after code");
        AuthChallenge challenge = checkStateCookie();
        if (challenge != null) return challenge;

        AccessTokenResponse tokenResponse = null;
        strippedOauthParametersRequestUri = stripOauthParametersFromRedirect();

        try {
            // For COOKIE store we don't have httpSessionId and single sign-out won't be available
            String httpSessionId = deployment.getTokenStore() == TokenStore.SESSION ? reqAuthenticator.changeHttpSessionId(true) : null;
            tokenResponse = ServerRequest.invokeAccessCodeToToken(deployment, code, rewrittenRedirectUri(strippedOauthParametersRequestUri), httpSessionId);
        } catch (ServerRequest.HttpFailure failure) {
            log.error("failed to turn code into token");
            log.error("status from server: " + failure.getStatus());
            if (failure.getError() != null) {
                log.error("   " + failure.getError());
            }
            return challenge(403, OIDCAuthenticationError.Reason.CODE_TO_TOKEN_FAILURE, null);

        } catch (IOException e) {
            log.error("failed to turn code into token", e);
            return challenge(403, OIDCAuthenticationError.Reason.CODE_TO_TOKEN_FAILURE, null);
        }

        tokenString = tokenResponse.getToken();
        refreshToken = tokenResponse.getRefreshToken();
        idTokenString = tokenResponse.getIdToken();

        log.debug("Verifying tokens");
        if (log.isTraceEnabled()) {
            logToken("\taccess_token", tokenString);
            logToken("\tid_token", idTokenString);
            logToken("\trefresh_token", refreshToken);
        }

        try {
            token = AdapterRSATokenVerifier.verifyToken(tokenString, deployment);
            if (idTokenString != null) {
                try {
                    JWSInput input = new JWSInput(idTokenString);
                    idToken = input.readJsonContent(IDToken.class);
                } catch (JWSInputException e) {
                    throw new VerificationException();
                }
            }
            log.debug("Token Verification succeeded!");
        } catch (VerificationException e) {
            log.error("failed verification of token: " + e.getMessage());
            return challenge(403, OIDCAuthenticationError.Reason.INVALID_TOKEN, null);
        }
        if (tokenResponse.getNotBeforePolicy() > deployment.getNotBefore()) {
            deployment.updateNotBefore(tokenResponse.getNotBeforePolicy());
        }
        if (token.getIssuedAt() < deployment.getNotBefore()) {
            log.error("Stale token");
            return challenge(403, OIDCAuthenticationError.Reason.STALE_TOKEN, null);
        }
        log.debug("successful authenticated");
        return null;
    }

rewrittenRedirectUri()

String org.keycloak.adapters.OAuthRequestAuthenticator.rewrittenRedirectUri ( String  originalUri )

inlineprivate

                                                            {
        Map<String, String> rewriteRules = deployment.getRedirectRewriteRules();
            if(rewriteRules != null && !rewriteRules.isEmpty()) {
            try {
                URL url = new URL(originalUri);
                Map.Entry<String, String> rule =  rewriteRules.entrySet().iterator().next();
                StringBuilder redirectUriBuilder = new StringBuilder(url.getProtocol());
                redirectUriBuilder.append("://"+ url.getAuthority());
                redirectUriBuilder.append(url.getPath().replaceFirst(rule.getKey(), rule.getValue()));
                return redirectUriBuilder.toString();
            } catch (MalformedURLException ex) {
                log.error("Not a valid request url");
                throw new RuntimeException(ex);
            }
            }
        return originalUri;
    }

setIdToken()

void org.keycloak.adapters.OAuthRequestAuthenticator.setIdToken ( IDToken  idToken )

inline

                                            {
        this.idToken = idToken;
    }

setIdTokenString()

void org.keycloak.adapters.OAuthRequestAuthenticator.setIdTokenString ( String  idTokenString )

inline

                                                       {
        this.idTokenString = idTokenString;
    }

setStrippedOauthParametersRequestUri()

void org.keycloak.adapters.OAuthRequestAuthenticator.setStrippedOauthParametersRequestUri ( String  strippedOauthParametersRequestUri )

inline

                                                                                               {
        this.strippedOauthParametersRequestUri = strippedOauthParametersRequestUri;
    }

sslRedirectPort()

int org.keycloak.adapters.OAuthRequestAuthenticator.sslRedirectPort ( )

inlineprotected

                                    {
        return sslRedirectPort;
    }

stripOauthParametersFromRedirect()

String org.keycloak.adapters.OAuthRequestAuthenticator.stripOauthParametersFromRedirect ( )

inlineprotected

strip out unwanted query parameters and redirect so bookmarks don't retain oauth protocol bits

                                                        {
        KeycloakUriBuilder builder = KeycloakUriBuilder.fromUri(facade.getRequest().getURI())
                .replaceQueryParam(OAuth2Constants.CODE, null)
                .replaceQueryParam(OAuth2Constants.STATE, null)
                .replaceQueryParam(OAuth2Constants.SESSION_STATE, null);
        return builder.build().toString();
    }

メンバ詳解

challenge

AuthChallenge org.keycloak.adapters.OAuthRequestAuthenticator.challenge

protected

deployment

KeycloakDeployment org.keycloak.adapters.OAuthRequestAuthenticator.deployment

protected

facade

HttpFacade org.keycloak.adapters.OAuthRequestAuthenticator.facade

protected

idToken

IDToken org.keycloak.adapters.OAuthRequestAuthenticator.idToken

protected

idTokenString

String org.keycloak.adapters.OAuthRequestAuthenticator.idTokenString

protected

log

final Logger org.keycloak.adapters.OAuthRequestAuthenticator.log = Logger.getLogger(OAuthRequestAuthenticator.class)

staticprivate

refreshToken

String org.keycloak.adapters.OAuthRequestAuthenticator.refreshToken

protected

reqAuthenticator

RequestAuthenticator org.keycloak.adapters.OAuthRequestAuthenticator.reqAuthenticator

protected

sslRedirectPort

int org.keycloak.adapters.OAuthRequestAuthenticator.sslRedirectPort

protected

strippedOauthParametersRequestUri

String org.keycloak.adapters.OAuthRequestAuthenticator.strippedOauthParametersRequestUri

protected

token

AccessToken org.keycloak.adapters.OAuthRequestAuthenticator.token

protected

tokenStore

AdapterSessionStore org.keycloak.adapters.OAuthRequestAuthenticator.tokenStore

protected

tokenString

String org.keycloak.adapters.OAuthRequestAuthenticator.tokenString

protected

---

このクラス詳解は次のファイルから抽出されました:

• D:/AppData/OpenId/keycloak/doxygen/src/adapters/oidc/adapter-core/src/main/java/org/keycloak/adapters/OAuthRequestAuthenticator.java
