org.keycloak.protocol.oidc.OIDCLoginProtocolFactory クラス

org.keycloak.protocol.oidc.OIDCLoginProtocolFactory の継承関係図

org.keycloak.protocol.oidc.OIDCLoginProtocolFactory 連携図

公開メンバ関数
LoginProtocol	create (KeycloakSession session)
Map< String, ProtocolMapperModel >	getBuiltinMappers ()
Object	createProtocolEndpoint (RealmModel realm, EventBuilder event)
String	getId ()
void	setupClientDefaults (ClientRepresentation rep, ClientModel newClient)
void	init (Config.Scope config)
void	postInit (KeycloakSessionFactory factory)
void	createDefaultClientScopes (RealmModel newRealm, boolean addScopesToExistingClients)
void	close ()
default int	order ()

静的公開変数類
static final String	USERNAME = "username"
static final String	EMAIL = "email"
static final String	EMAIL_VERIFIED = "email verified"
static final String	GIVEN_NAME = "given name"
static final String	FAMILY_NAME = "family name"
static final String	MIDDLE_NAME = "middle name"
static final String	NICKNAME = "nickname"
static final String	PROFILE_CLAIM = "profile"
static final String	PICTURE = "picture"
static final String	WEBSITE = "website"
static final String	GENDER = "gender"
static final String	BIRTHDATE = "birthdate"
static final String	ZONEINFO = "zoneinfo"
static final String	UPDATED_AT = "updated at"
static final String	FULL_NAME = "full name"
static final String	LOCALE = "locale"
static final String	ADDRESS = "address"
static final String	PHONE_NUMBER = "phone number"
static final String	PHONE_NUMBER_VERIFIED = "phone number verified"
static final String	PROFILE_SCOPE_CONSENT_TEXT = "${profileScopeConsentText}"
static final String	EMAIL_SCOPE_CONSENT_TEXT = "${emailScopeConsentText}"
static final String	ADDRESS_SCOPE_CONSENT_TEXT = "${addressScopeConsentText}"
static final String	PHONE_SCOPE_CONSENT_TEXT = "${phoneScopeConsentText}"
static final String	OFFLINE_ACCESS_SCOPE_CONSENT_TEXT = Constants.OFFLINE_ACCESS_SCOPE_CONSENT_TEXT

限定公開メンバ関数
void	createDefaultClientScopesImpl (RealmModel newRealm)
void	addDefaults (ClientModel client)
void	addDefaultClientScopes (RealmModel realm, ClientModel newClient)

静的関数
	[static initializer]

静的変数
static Map< String, ProtocolMapperModel >	builtins = new HashMap<>()

静的非公開メンバ関数
static void	createUserAttributeMapper (String name, String attrName, String claimName, String type)

静的非公開変数類
static final Logger	logger = Logger.getLogger(OIDCLoginProtocolFactory.class)

詳解

著者

Bill Burke

バージョン

Revision

1

関数詳解

[static initializer]()

org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.[static initializer] ( )

inlinestaticpackage

addDefaultClientScopes()

void org.keycloak.protocol.AbstractLoginProtocolFactory.addDefaultClientScopes ( RealmModel  realm, ClientModel  newClient  )

inlineprotectedinherited

                                                                                   {
        for (ClientScopeModel clientScope : realm.getDefaultClientScopes(true)) {
            if (getId().equals(clientScope.getProtocol())) {
                newClient.addClientScope(clientScope, true);
            }
        }
        for (ClientScopeModel clientScope : realm.getDefaultClientScopes(false)) {
            if (getId().equals(clientScope.getProtocol())) {
                newClient.addClientScope(clientScope, false);
            }
        }
    }

addDefaults()

void org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.addDefaults ( ClientModel  client )

inlineprotected

                                                   {
    }

close()

void org.keycloak.protocol.AbstractLoginProtocolFactory.close ( )

inlineinherited

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                        {

    }

create()

LoginProtocol org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.create ( KeycloakSession  session )

inline

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                                                         {
        return new OIDCLoginProtocol().setSession(session);
    }

createDefaultClientScopes()

void org.keycloak.protocol.AbstractLoginProtocolFactory.createDefaultClientScopes ( RealmModel  newRealm, boolean  addScopesToExistingClients  )

inlineinherited

org.keycloak.protocol.LoginProtocolFactoryを実装しています。

                                                                                                   {
        createDefaultClientScopesImpl(newRealm);

        // Create default client scopes for realm built-in clients too
        if (addScopesToExistingClients) {
            for (ClientModel client : newRealm.getClients()) {
                addDefaultClientScopes(newRealm, client);
            }
        }
    }

createDefaultClientScopesImpl()

void org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.createDefaultClientScopesImpl ( RealmModel  newRealm )

inlineprotected

                                                                      {
        //name, family_name, given_name, middle_name, nickname, preferred_username, profile, picture, website, gender, birthdate, zoneinfo, locale, and updated_at.
        ClientScopeModel profileScope = newRealm.addClientScope(OAuth2Constants.SCOPE_PROFILE);
        profileScope.setDescription("OpenID Connect built-in scope: profile");
        profileScope.setDisplayOnConsentScreen(true);
        profileScope.setConsentScreenText(PROFILE_SCOPE_CONSENT_TEXT);
        profileScope.setProtocol(getId());
        profileScope.addProtocolMapper(builtins.get(FULL_NAME));
        profileScope.addProtocolMapper(builtins.get(FAMILY_NAME));
        profileScope.addProtocolMapper(builtins.get(GIVEN_NAME));
        profileScope.addProtocolMapper(builtins.get(MIDDLE_NAME));
        profileScope.addProtocolMapper(builtins.get(NICKNAME));
        profileScope.addProtocolMapper(builtins.get(USERNAME));
        profileScope.addProtocolMapper(builtins.get(PROFILE_CLAIM));
        profileScope.addProtocolMapper(builtins.get(PICTURE));
        profileScope.addProtocolMapper(builtins.get(WEBSITE));
        profileScope.addProtocolMapper(builtins.get(GENDER));
        profileScope.addProtocolMapper(builtins.get(BIRTHDATE));
        profileScope.addProtocolMapper(builtins.get(ZONEINFO));
        profileScope.addProtocolMapper(builtins.get(LOCALE));
        profileScope.addProtocolMapper(builtins.get(UPDATED_AT));

        ClientScopeModel emailScope = newRealm.addClientScope(OAuth2Constants.SCOPE_EMAIL);
        emailScope.setDescription("OpenID Connect built-in scope: email");
        emailScope.setDisplayOnConsentScreen(true);
        emailScope.setConsentScreenText(EMAIL_SCOPE_CONSENT_TEXT);
        emailScope.setProtocol(getId());
        emailScope.addProtocolMapper(builtins.get(EMAIL));
        emailScope.addProtocolMapper(builtins.get(EMAIL_VERIFIED));

        ClientScopeModel addressScope = newRealm.addClientScope(OAuth2Constants.SCOPE_ADDRESS);
        addressScope.setDescription("OpenID Connect built-in scope: address");
        addressScope.setDisplayOnConsentScreen(true);
        addressScope.setConsentScreenText(ADDRESS_SCOPE_CONSENT_TEXT);
        addressScope.setProtocol(getId());
        addressScope.addProtocolMapper(builtins.get(ADDRESS));

        ClientScopeModel phoneScope = newRealm.addClientScope(OAuth2Constants.SCOPE_PHONE);
        phoneScope.setDescription("OpenID Connect built-in scope: phone");
        phoneScope.setDisplayOnConsentScreen(true);
        phoneScope.setConsentScreenText(PHONE_SCOPE_CONSENT_TEXT);
        phoneScope.setProtocol(getId());
        phoneScope.addProtocolMapper(builtins.get(PHONE_NUMBER));
        phoneScope.addProtocolMapper(builtins.get(PHONE_NUMBER_VERIFIED));

        // 'profile' and 'email' will be default scopes for now. 'address' and 'phone' will be optional scopes
        newRealm.addDefaultClientScope(profileScope, true);
        newRealm.addDefaultClientScope(emailScope, true);
        newRealm.addDefaultClientScope(addressScope, false);
        newRealm.addDefaultClientScope(phoneScope, false);

        RoleModel offlineRole = newRealm.getRole(OAuth2Constants.OFFLINE_ACCESS);
        if (offlineRole != null) {
            ClientScopeModel offlineAccessScope = KeycloakModelUtils.getClientScopeByName(newRealm, OAuth2Constants.OFFLINE_ACCESS);
            if (offlineAccessScope == null) {
                DefaultClientScopes.createOfflineAccessClientScope(newRealm, offlineRole);
            }
        }
    }

createProtocolEndpoint()

Object org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.createProtocolEndpoint ( RealmModel  realm, EventBuilder  event  )

inline

org.keycloak.protocol.LoginProtocolFactoryを実装しています。

                                                                               {
        return new OIDCLoginProtocolService(realm, event);
    }

createUserAttributeMapper()

static void org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.createUserAttributeMapper ( String  name, String  attrName, String  claimName, String  type  )

inlinestaticprivate

                                                                                                               {
        ProtocolMapperModel model = UserAttributeMapper.createClaimMapper(name,
                attrName,
                claimName, type,
                true, true, false);
        builtins.put(name, model);
    }

getBuiltinMappers()

Map<String, ProtocolMapperModel> org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.getBuiltinMappers ( )

inline

org.keycloak.protocol.LoginProtocolFactoryを実装しています。

                                                                {
        return builtins;
    }

getId()

String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.getId ( )

inline

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                          {
        return OIDCLoginProtocol.LOGIN_PROTOCOL;
    }

init()

void org.keycloak.protocol.AbstractLoginProtocolFactory.init ( Config.Scope  config )

inlineinherited

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                                          {
    }

order()

default int org.keycloak.provider.ProviderFactory< T extends Provider >.order ( )

inlineinherited

org.keycloak.protocol.docker.DockerAuthV2ProtocolFactory, org.keycloak.urls.HostnameProviderFactory, org.keycloak.protocol.oidc.ext.OIDCExtProviderFactoryで実装されています。

                        {
        return 0;
    }

postInit()

void org.keycloak.protocol.AbstractLoginProtocolFactory.postInit ( KeycloakSessionFactory  factory )

inlineinherited

org.keycloak.provider.ProviderFactory< T extends Provider >を実装しています。

                                                         {
        factory.register(new ProviderEventListener() {
            @Override
            public void onEvent(ProviderEvent event) {
                if (event instanceof RealmModel.ClientCreationEvent) {
                    ClientModel client = ((RealmModel.ClientCreationEvent)event).getCreatedClient();
                    addDefaultClientScopes(client.getRealm(), client);
                    addDefaults(client);
                }
            }
        });
    }

setupClientDefaults()

void org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.setupClientDefaults ( ClientRepresentation  rep, ClientModel  newClient  )

inline

org.keycloak.protocol.LoginProtocolFactoryを実装しています。

                                                                                     {
        if (rep.getRootUrl() != null && (rep.getRedirectUris() == null || rep.getRedirectUris().isEmpty())) {
            String root = rep.getRootUrl();
            if (root.endsWith("/")) root = root + "*";
            else root = root + "/*";
            newClient.addRedirectUri(root);

            Set<String> origins = new HashSet<String>();
            String origin = UriUtils.getOrigin(root);
            logger.debugv("adding default client origin: {0}" , origin);
            origins.add(origin);
            newClient.setWebOrigins(origins);
        }
        if (rep.isBearerOnly() == null
                && rep.isPublicClient() == null) {
            newClient.setPublicClient(true);
        }
        if (rep.isBearerOnly() == null) newClient.setBearerOnly(false);
        if (rep.getAdminUrl() == null && rep.getRootUrl() != null) {
            newClient.setManagementUrl(rep.getRootUrl());
        }


        // Backwards compatibility only
        if (rep.isDirectGrantsOnly() != null) {
            ServicesLogger.LOGGER.usingDeprecatedDirectGrantsOnly();
            newClient.setStandardFlowEnabled(!rep.isDirectGrantsOnly());
            newClient.setDirectAccessGrantsEnabled(rep.isDirectGrantsOnly());
        } else {
            if (rep.isStandardFlowEnabled() == null) newClient.setStandardFlowEnabled(true);
            if (rep.isDirectAccessGrantsEnabled() == null) newClient.setDirectAccessGrantsEnabled(true);

        }

        if (rep.isImplicitFlowEnabled() == null) newClient.setImplicitFlowEnabled(false);
        if (rep.isPublicClient() == null) newClient.setPublicClient(true);
        if (rep.isFrontchannelLogout() == null) newClient.setFrontchannelLogout(false);
    }

メンバ詳解

ADDRESS

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.ADDRESS = "address"

static

ADDRESS_SCOPE_CONSENT_TEXT

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.ADDRESS_SCOPE_CONSENT_TEXT = "${addressScopeConsentText}"

static

BIRTHDATE

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.BIRTHDATE = "birthdate"

static

builtins

Map<String, ProtocolMapperModel> org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.builtins = new HashMap<>()

staticpackage

EMAIL

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.EMAIL = "email"

static

EMAIL_SCOPE_CONSENT_TEXT

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.EMAIL_SCOPE_CONSENT_TEXT = "${emailScopeConsentText}"

static

EMAIL_VERIFIED

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.EMAIL_VERIFIED = "email verified"

static

FAMILY_NAME

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.FAMILY_NAME = "family name"

static

FULL_NAME

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.FULL_NAME = "full name"

static

GENDER

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.GENDER = "gender"

static

GIVEN_NAME

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.GIVEN_NAME = "given name"

static

LOCALE

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.LOCALE = "locale"

static

logger

final Logger org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.logger = Logger.getLogger(OIDCLoginProtocolFactory.class)

staticprivate

MIDDLE_NAME

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.MIDDLE_NAME = "middle name"

static

NICKNAME

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.NICKNAME = "nickname"

static

OFFLINE_ACCESS_SCOPE_CONSENT_TEXT

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.OFFLINE_ACCESS_SCOPE_CONSENT_TEXT = Constants.OFFLINE_ACCESS_SCOPE_CONSENT_TEXT

static

PHONE_NUMBER

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.PHONE_NUMBER = "phone number"

static

PHONE_NUMBER_VERIFIED

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.PHONE_NUMBER_VERIFIED = "phone number verified"

static

PHONE_SCOPE_CONSENT_TEXT

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.PHONE_SCOPE_CONSENT_TEXT = "${phoneScopeConsentText}"

static


final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.PICTURE = "picture"

static

PROFILE_CLAIM

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.PROFILE_CLAIM = "profile"

static

PROFILE_SCOPE_CONSENT_TEXT

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.PROFILE_SCOPE_CONSENT_TEXT = "${profileScopeConsentText}"

static

UPDATED_AT

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.UPDATED_AT = "updated at"

static

USERNAME

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.USERNAME = "username"

static

WEBSITE

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.WEBSITE = "website"

static

ZONEINFO

final String org.keycloak.protocol.oidc.OIDCLoginProtocolFactory.ZONEINFO = "zoneinfo"

static

---

このクラス詳解は次のファイルから抽出されました:

• D:/AppData/doxygen/keycloak/src/keycloak/src/main/java/org/keycloak/protocol/oidc/OIDCLoginProtocolFactory.java
